Capacity: | 5t/h | Power: | 37kw |
---|---|---|---|
Weight: | 1300kg |
oat peeler, oats peeling machine, barley peeler, barley peeling machine
The machine made by feeding structure, screw propeller, peeling chamber, emery roller, transmission , collection hopper, discharge device, and dust remover, etc.
The wheat corn peeling machine use high-speed rotating emery roller for continuous cutting and friction to maize or wheat, effectively remove corn, wheat and beans skin. Durable emery roll,simple maintain and easy to operate.
The peeling machine suitable for wheat, oat, corn, sorghum, soybean, green bean, broad bean, kidney bean, pea, lentil, chickpea, etc grain processing. beans peeling machine inner structure different.
Specification :
Model |
FDTP-18A |
FDTP-18B |
FDTP-25A |
FDTP-25B |
FDTP-30Y/A |
Emery roll diameter |
Φ180mm |
Φ180mm |
Φ240 |
Φ240 |
Φ300 |
Emery roll length |
660mm |
660mm |
660mm |
660mm |
800mm |
Rotating speed |
1300r/min |
1300r/min |
1050r/min |
1050r/min |
850r/min |
Capacity |
1-1.5t/h |
1-1.5t/h |
2.5-3.5t/h |
2.5-3.5t/h |
4-6t/h |
Power |
22kw |
22kw |
30kw |
30kw |
37-45kw |
Weight |
800kg |
800kg |
1000kg |
1000kg |
1300kg |
Dimension |
1370*700*1900mm |
1410*1220*2030mm |
1515*660*2100mm |
1515*1220*2100mm |
1690*710*2180mm |
